Home > KAWASAKI > Starter Rebuild Parts for 2001-11 UTV Kawasaki KAF620 MULE 3000 3010 3020 4000 4010 - 18629

Starter Denso 228000-8841

Starter Rebuild Parts for 2001-11 UTV Kawasaki KAF620 MULE 3000 3010 3020 4000 4010 - 18629
Item #:18629
Your Price:$199.99
Quantity:

Product Description

Starter

Denso OSGR, 1.2kW/12 Volt, CCW, 9-Tooth Pinion
Rebuild Parts List Below
Cross Reference: Denso 228000-8841, Kawasaki 21163-2124, 21163-6010, Other: 18629

Application

Kawasaki Utility Vehicle
KAF620 Mule 3000 617cc 2001-2008
KAF620 Mule 3010 4x4 617cc 2001-2008
KAF620 Mule 3010 Trans 4x4 617cc 2005-2008
KAF620 Mule 3020 617cc 2001-2003
KAF620 Mule 4000 617cc 2009-2010
KAF620 Mule 4010 4x4 617cc 2009-2011
KAF620 Mule 4010 Trans 4x4 617cc 2009-2011
Suzuki Utility Vehicle QUV620F 620cc 2005
Starter Rebuild Parts for 2001-11 UTV Kawasaki KAF620 MULE 3000 3010 3020 4000 4010 - Denso 228000-8841, Kawasaki 21163-2124, 21163-6010 // Armature, 50903203 Ball, Steel, 69909900 Bearing, 52204 53203 53706 54208 Boot, 92909032 Brush Holder Assy, 55909024 Brush, 54903210 54903211 Contact & Plunger Assy 67909023 Contact, 6790926 6790904 Cover, Soln 6790215 Gasket, Soln 91909009 Gear, 69909608 Nut 9590004 O-Ring 91909052 91909054 Pinion, Drive 62902010 Retainer, 6990136 Roller, 6990135 Screw 96909004 Spring, Brush, 94909003 Spring, Plunger, 67909133 Spring, Drive 62902610T Thru Bolt 9603300 Tube, Drain, 91909017
