Home > Alternator 160 Amp Pad Mount Leece Neville Prestolite LBP2180, LBP2180GH, 110-912 - 8502

Alternator Replacing LBP2180

Alternator 160 Amp Pad Mount Leece Neville Prestolite LBP2180, LBP2180GH, 110-912 - 8502
Item #:8502
Your Price:$318.89
Quantity:

Product Description
**This Item only ships to USA Addresses / 2-3 Day Delays for Outside the continental 48 states // **Availability on complete units may vary. You will be notified if your order can not ship immediately and/or you can contact us to verify availability if needed - Thank you!

QUALITY AFTERMARKET ALTERNATOR - 1 YEAR WARRANTY

Leece-Neville / Motorola 8LHP Series 160 Amp/12 Volt, CW, w/o Pulley, 4-Point Pad Mount

Parts List for Leece Neville LBP2180

Bearing Retainer Early Version, DE Bearing 1 85707001 111-35
Bearing, Ball Early Version, SRE Housing 1 103475
Bearing, Ball Early Version, DE Housing 1 56200 103473
Brush Holder Assembly 1 74101403 103-63
Diode Positive 3 171-16014 102-59
Diode Negative 3 171-16015 102-60
Fan 1 7870710 A041102916S
Gasket Brush Holder 1 91708003 103-49
Heat Sink 1 77103560 101-190
Heat Sink 1 77103561 101-191
Housing, DE OEM Version Includes Bearing, Retainer & Spacer 1 A014103264S
Housing, DE 1 7610129 114-305
Housing, SRE OEM Version Includes Rectifier 1 A011103690S
Housing, SRE 1 7570507 114-304
Insulating Bushing Output Stud 1 92707009 115-24
Insulating Bushing 5 92101314 92707013 115-7
Insulating Bushing Rectifier 2 92101303 115-27
Insulating Bushing SRE Housing 1 92101312 115-9
Insulating Bushing Rectifier Attaching 4 92101311 115-76
Insulating Bushing Output Stud 1 92707007 115-12
Insulating Washer Diode 6 115-81
Insulating Washer SRE Housing 5 115-82
Insulating Washer Stud 1 92505026 115-10
Insulating Washer Stud 1 92303000 115-20
Key, Woodruff Rotor Shaft 1 9300003 6399
Kit, Alternator Repair OEM Version Includes High Temperature Grease Bearings, Brush Holder, O-Ring & Slip Ring 1 K183104053S
Kit, Alternator Repair OEM Version Includes ALL Hardware Needed for this Unit 1 K212104110S
Lead Rectifier 2 116-148
Lead Connect Diodes 1 116-149
Nut, Hex SRE Housing 1 95001232 9510001 120-157
Nut, Hex-Washer SRE Housing 8 95001224
Nut, Hex-Washer SRE Housing 2 95001200 120-377
Nut, Self-Locking Hex Pulley Mounting 1 95001302 95001303 120-128
O-Ring SRE Bearing Retainer 1 91707210 111-86
Other Terminal 1 79944
Rectifier Negative, Complete Rectifier Assembly Included with SRE Housing 1 102153
Rectifier Positive, Complete Rectifier Assembly Included with SRE Housing 1 102154
Regulator, Electronic OEM Version Includes Gasket 1 8010329 105-360
Rotor 1 70101191 A020102145S
Screw 6 96707102 120-252
Screw SRE Housing Attaching 3 96707103 120-153
Slip Ring 1 7110100 v 112-22
Spacer SRE Bearing 1 120-159
Stator 1 72101347 0180000F29S
Stud Leece Neville Refers to This as an "Open Barrel Terminal" 3 2944873B05
Stud, Phase 3 96100002 120-412
Stud, Rectifier Negative 1 9670118 120-94
Stud, Relay/Sense/Indicator Positive 1 9670121 120-185
Thru Bolt 4 96707105 120-364
Washer, Felt 1 91707204 111-18
Washer, Flat SRE Housing 3 120-378
Washer, Flat Rectifier Stud Attaching 2 97404001 120-109
Washer, Flat Stud 1 97001000 120-189
Washer, Flat Pulley Mounting 1 97404050 120-129
Washer, Lock, Split 3 97001510 120-111
Washer, Lock, Split SRE Housing 1 97001512 120-26
